MultiControl II duo and MultiControl II quadro assembly instructions
Moving drive groups in parallel
During parallel movement, both drive groups are moved simultaneously but not
in a synchronised manner. The drive groups move at their respective, configured
speed. If a drive group stops at an end position during parallel movement, the
other drive group continues to move.
No drive group is activated for parallel movement.
Moving drive groups in sync
During synchronous movement of the drive groups, the drive groups move at
their respective, configured speed. If a drive group stops at an end position
during synchronous movement, the other drive group also stops.
Both drive groups are activated for synchronous movement.
Using a change
the travel speed of the second drive group for the synchronous
movement. Hall sensor conditions are changed by changing a parameter
(parameter 111). Please consult chapter „6.5.6.14 Changing parameters" for
information on how to change the parameters for MultiControl II.
Parameter 111 can be configured from 2000 (factor 0.2) to 60000 (factor 6.0).
The factory setting is 10000 - this equals a factor 1.
in the hall sensor
Parameter 111 operates only while the drive groups are
moved synchronously.
conditions, you can adjust
