6

Life Phases

6.1

Transport and storage

Damage due to transport and storage is to be reported to the line manager and to RK
Rose+Krieger GmbH immediately.
The product is to be inspected by qualified staff for visual and functional damage. It is forbidden
to put damaged controllers into operation.
The following ambient conditions have been specified for storing the controls:
• Contact with solvent-based paints must be avoided.
• Lowest/highest ambient temperature: -25 °C/+80 °C
• Relative humidity in storage: falling below the dew point is not permitted
Divergent environmental factors must be approved by RK Rose+Krieger GmbH.
6.2

Installation

6.2.1 MultiControl II duo and quadro

The
(4 x Ø 5.5 mm) designated for fixing. Figure 2 shows the positions of the holes,
using the MultiControl II duo as an example.
Figure 2 - MultiControl II duo attachment points
86
controls must
MultiControl II duo and MultiControl II quadro assembly instructions
only be attached using the holes
