The current position of the drives can be stored as follows:
• Press the "F" key to open the quick menu.
• Press function key 1 to select the position to be stored.
• With function keys 1 or 2, you store the current position of the drive
under I or II.
The selected user and the stored position are still stored, even after switching off
the control.
6.5.5.3

Moving up to a stored position

If you wish to move to a stored position for the active user, press and hold the
respective function key 1 or 2 until the position is reached.
6.5.5.4

Changing the user

The currently active user can be seen at the top right of the display.
• Press the "F" key to open the quick menu.
-›› The quick menu display as shown in Figure 12 opens.
• Press function key 2 to select the active user.
• Select a user (1 – 3), using the "DOWN" key or "UP" key.
• Press function key 1 to confirm the
selection or function key 2 to cancel the
procedure.
-›› The new user is now activated
and is shown on the display.
MultiControl II duo and MultiControl II quadro assembly instructions
Figure 12 - Quick menu
