MultiControl II duo and MultiControl II quadro assembly instructions
6.5.7.5

Drive group management

Figure 19 displays the hand switch in the
"Drive group management" view.
You can activate one or both drive groups with function keys 1 and 2. You can
manually move the active drives to the desired position by pressing the "UP" or
"DOWN" function key respectively.
Pressing
F
key
positioning
for
"F" key again takes you back to the main display for "Drive group management"
(see Figure 19).
The drive group management function is only available in the Premium version of the
MultiControl II quadro and enables two specified drive groups on one MultiControl II
quadro to be adjusted independently of each other or in parallel to each other.
Figure 19 - Drive group management
allows
you
to
the
activated
If drive group management is activated and a display
"Memory position" or respectively, relative or absolute
positioning is configured, the groups can be activated
or deactivated as follows:
› Press and hold the "F" key.
› Press function keys 1 and 2.
-›› The active drive groups on the
top edge of the display are shown as G1, G2,
G= (both groups activated - synchronous
movement) or G≠ (no group activated -
parallel movement).
Synchronous movement of both drive groups "G=" is
not possible via a memory position.
switch
to
absolute
drive
groups
or
relative
pressing
the
121
