3-bit screen for stored position
Speed (fast/slow)
Acknowledge error
Stored positions can be assigned using the hand switch with 6 function keys (see chapter
6.5.6.8).
Description of the outputs:
Output voltage level
O1- O8
RS485 A/B
Voltage supply for
digital outputs
1
2
3
4
5
6
7
8
The I/O interface module has no galvanic isolation. The GND is continuous.
A power supply for digital outputs on terminals 23 – 24 must be provided by an external
source.
MultiControl II duo and MultiControl II quadro assembly instructions
Outputs Terminal
13 - 20
21, 22
23
24
13
14
15
16
17
18
19
20
Stored position number for the position.
Changes the speed of the system. When
high level is active, silent running is activated.
The speed is set using Parameter 17 (see
chapter 6.5.6.14).
resets the active state of an error, provided
that this is possible.
Standard function
High: corresponds to the
voltage on terminal 23
Low: GND
A / B
+ Digital output: 10-30 VDC,
max. 4 A
GND
Error state
Initialised
Position reached
Active movement
N/A
Neutral position
Encoder replication A
Encoder replication B
Logic level
-
-
-
High-active
High-active
High-active
High-active
-
Low-active
High/Low
High/Low
