Routing of electrical leads
When routing electrical leads, ensure that
The screws for installing the control on the supporting surface are not included in the
product's scope of delivery and must be provided by the customer. Only use screws with
a cylindrical contact surface for installation.
The following instructions for the selection and installation of the fastening screws must
be observed:
MultiControl II duo and MultiControl II quadro assembly instructions
• these cannot become trapped,
• no mechanical load is exerted on them,
• they are undamaged in any other way and
• obstacles do not pose any risks to persons.
• Max. screw head diameter: 10.0 mm
• Min. screw head diameter: 8.0 mm
• Max. screw diameter: 5.5 mm
• Push-through depth for the control: 20.5 mm
• Max. tightening torque: 1.5 Nm
Use fastening screws with sufficient strength. A strength
of 8.8 is recommended when following the recommended
minimum screw-in depths.
