RK Rose+Krieger RK MultiControl II duo Montageanleitung Seite 129

Code
E11 Contouring error between
controller 1 and motor 1
E12 Contouring error between
controller 2 and motor 2
E13 External stop signal was set
E21 Safety edge not connected or
cable break
E22 Safety edge activated during
movement
E23 SPP collision detected
E24 Overvoltage in intermediate
circuit
E31 Error slave 1 to 7
-E37
E38 Error, serial communication on
the Control-BUS interrupted
E39 Error, serial communication on
the sync bus interrupted
E41 Error, limit switch
configuration (wrong drive)
E42 Master to slave difference too
great
E45 Internal error
E51 Faulty entry in the memory
has been detected
E52 Internal error
E71 Error, drive 3 motor current
excessively high
E72 Error, drive 4 motor current
excessively high
E73 Blockade detected on drive 3
E74 Blockade detected on drive 4
E75 Contouring error between
controller 3 and drive 3
E76 Contouring error between
controller 4 and drive 4
MultiControl II duo and MultiControl II quadro assembly instructions
Description Troubleshooting
Check the drive for mechanical overload. The drive
may be faulty.
Check the settings of the control of the system for
possible errors.
The fault is eliminated after the contact has been
re-established.
Free movement opposite to the last direction of
movement. When the error code is displayed, first
acknowledge with a function key.
Mechanical blockade detected - adjust the SPP's
possible sensitivity.
Check the load of the drives.
Check the displayed slave control. Perform an
initialisation run.
Check the connection. The hand switch may be
faulty.
Check the connections in the synchro network
system or of the individual connected controls.
Use a drive that is suitable for the configuration of
the control.
Check the drive for mechanical overload. A drive is
possibly defective.
Contact RK Rose+Krieger GmbH
The control is automatically reset to the factory
settings, An initialisation run is required.
Contact RK Rose+Krieger GmbH
If the fault is appearing frequently, check your
system for mechanical overload.
Check the system for mechanical blockages.
Check the drive for mechanical overload. The drive
may be faulty.
