5

Product Information

5.1

Mode of operation

The MultiControl II duo and MultiControl II quadro controls can be used to move the RK
Rose+Krieger GmbH drives (see chapter 6.7).
Depending on the configuration (MultiControl II duo / MultiControl II quadro), you can connect
up to four drives per control. You use a hand switch to operate the controller. This hand switch
can optionally have two or six function keys (see 6.4 and 6.5). Through a synchronisation bus
(Sync-BUS), up to eight controls can be connected to each other and therefore up to 32 drives
can be moved synchronously (see chapter „6.7 Suitable drives").
5.2

Technical data

Characteristic
Dimensions W × H x L
Weight
Supply voltage (primary)
Protection class
max. current consumption
(primary)
max. number of drives
max. output current
Nominal and output voltage
Duty cycle
Rated output
Standby power
consumption*
Protection class
Primary fuse rating
Ambient temperature
Ambient air pressure
Relative humidity
* = Standby power consumption is higher in combination with Multilift I / Multilift synchro.
84
MultiControl II duo
800 g
Under nominal load 20% ED / 20 min runtime
< 0.5 W
+5 deg. Celsius to +40 deg. Celsius
MultiControl II duo and MultiControl II quadro assembly instructions
MultiControl II quadro
240 mm x 105 mm x 56 mm
100 - 240 VAC, 50/60 Hz
IP 20
3.5 A at 100 VAC;
3.0 A at 115 VAC;
1.5 A at 230 VAC;
2
5 A per drive, 10 A total
28.5 VDC ± 2%
(4 min. operation, 16 min. break)
350 VA
I, secondary SELV
2 x 4 A fast-acting
700 hPa to 1600 hPa
30% to 75%
1000 g
4
< 1.0 W
