▪ W = abbreviation for week
▪ ww = calendar week
4.7

Type key

Example: Wilo-Padus UNI M05B/T15-540/A
UNI Series
M Impeller shape = multi-channel impeller
05 Nominal diameter of pressure connection
Material version
B - n/a = standard version
- B = version in V4A
T Mains connection version: M = 1~, T = 3~
15 /10 = rated power P in kW
2
5 Mains connection frequency: 5 = 50 Hz, 6 = 60 Hz
40 Key for rated voltage
Additional electrical equipment:
n/a = with bare cable end
A A = with float switch and plug
VA = with vertical float switch and plug
P = with plug
4.8

Scope of delivery

▪ Pump with 10 m (33 ft) cable
▪ Single-phase current version with
– Shockproof plug
– Float switch and shockproof plug
▪ Three-phase current version with
– Bare cable end
– Float switch and CEE plug
▪ Installation and operating instructions
4.9

Accessories

▪ Cable lengths in fixed length increments of 10 m (33 ft)
up to max. 30 m (99 ft) in single-phase current version or
max. 50 m (164 ft) in three-phase current version
▪ Suspension unit
▪ Level control devices
▪ Fixation accessories and chains
▪ Switchgear, relays and plugs
5

Transportation and storage

5.1

Delivery

After receiving the shipment, this must be checked im-
mediately for defects (damage, completeness). Defects
must be noted on the freight documentation! Further-
more, defects must be notified to the transport company
or the manufacturer immediately on the day of receipt of
Installation and operating instructions Wilo-Padus UNI
Transportation and storage
shipment. Subsequently notified defects can no longer
be asserted.
5.2

Transport

WARNING
Standing under suspended loads!
Never allow anyone to stand under suspended loads!
Danger of (serious) injuries caused by falling parts.
Loads may not be carried over work places where
people are present!
WARNING
Head and foot injuries due to a lack of protect-
ive equipment!
Danger of (serious) injuries during work. Wear the fol-
lowing protective equipment:
• Safety shoes
• Safety helmet must be worn if lifting equipment
are used!
NOTICE
Use only properly functioning lifting equip-
ment!
Use only properly functioning lifting equipment to lift
and lower the pump. Ensure that the pump does not
become jammed during lifting and lowering. Do not
exceed the maximum bearing capacity of the lifting
equipment! Check that lifting equipment is function-
ing properly before use!
CAUTION
Soaked packaging may tear!
The product may fall on the ground if unprotected
and may be damaged. Lift wet packaging carefully
and replace it immediately!
Only remove the outer packaging at the place of utilisa-
tion to ensure that the pump is not damaged during
transport. Use tear-proof plastic sacks of sufficient size
to package used pumps for transport in a leak-proof
manner.
The following points must also be observed:
