267mm
When desk mounted, you can securely fasten your scanner to your work
surface by screwing M6 safety bolts into your scanner's feet
NOTE Your safety is important to us and we strongly advise reading the warning
information on the following page before mounting your Cintel scanner.

Wall Mounting

Cintel's elegant industrial design and narrow profile make it ideal for wall mounting.
To do this, the first thing you'll need to do is remove the feet and support strut from the base
of your scanner.
1 Place your scanner face up with its feet over the edge of a solid, stable surface capable of
supporting your scanner's weight.
2 Unscrew the pair of M8 screws from each foot using a 6mm hex key, then gently
remove the feet.
3 Using a Phillips head screwdriver, remove the support strut between the feet. Store the
support strut in a safe place together with your scanner's feet so you can always reattach
them later if you need to relocate your scanner.
Your scanner's desk mount feet and support strut can be removed if you want to mount your scanner to a wall
Unpacking and Mounting 8
