Light Source Status Indicators
These indicators under the 'auto' button let you know if the auto black or auto white light
source calibration has been successful or if there are items to address. They also provide
a helpful reminder to recalibrate the LED light source to ensure the highest quality scans.
RGB Controls
By default, a color balance control lets you adjust all three color channels by varying amounts
to alter the color temperature of the light source used to illuminate the film, while the adjusted
R, G, and B values are displayed in three fields below. Optionally, you can choose to put this
control into 'color bars' mode using the mode pop-up to the right of the 'light source' title bar,
which changes this control to three vertical red, green, and blue color channel sliders.
NOTE The light source calibration is saved when you change rolls. This allows you to
scan multiple rolls with a single light source calibration in both SDR and HDR modes.
The last light source calibration will be saved until a new calibration is performed, or
until your Cintel Scanner is power cycled.

Image Stabilization

These controls let you enable and disable as well as control image stabilization to eliminate
vertical film hop and horizontal weave.
Image Stabilization controls in the media page
Light source calibration has not yet been performed.
Light source calibration has performed successfully.
Light source calibration failed. Verify you have the correct
film type selected, the light path is not obstructed and
a suitable reference frame is selected. If required, try
advancing film and selecting an alternate reference frame.
Light source calibration has successfully balanced colours
but not at desired levels. As a solution, you can accept the
balanced scan and optimize the image in DaVinci Resolve's
color page or select an alternate reference frame for
calibration with a wider dynamic range.
Capturing Using DaVinci Resolve 31
