Blackmagic Design Cintel Scanner Installations- Und Bedienungsanleitung Seite 6

12
1
11
2
10
4 9
3
6
5
8
7
1. Core clamp 2. Roller 3. Particle transfer roller 4. Optional Audio and KeyKode Reader
attached via left options interface 5. Tensioner wheel 6. Skid plate 7. Light source
8. Drive wheel 9. Pin registration expansion port 10. Compliance arm
11. Spooler backplate 12. Focus wheel
1
2
3
4
5
6
7
8
1. HDMI 2. PCIe 3. Thunderbolt 3 4. Power supply status 5. Bi-Phase sync / timecode out
6. XLR3 audio input 1 7. XLR3 audio input 2 8. Power connection
6
