Translation of the Original Instruction Manual
Fig. 1 – 9:
Fig. 1: View of inputs with operating panel and PRCD
Fig. 2: Operating panel of the input and control unit
Fig. 3: Connection to the water supply/installation
Fig. 4: View of outputs
Fig. 5: Flushing heating system/heating circuits
Fig. 6: Volume in l/m of different pipes
Fig. 7: Disinfection unit REMS V-Jet TW or cleaning and preservation
unit REMS V-Jet H
Fig. 8: Connecting hose compressor/water connections
Fig. 9: Printer
1 Fault current circuit breaker PRCD
2 RESET button
3 TEST button
4 On/Off button
5 Control lamp
6 Screen (LCD)
7 "?" button
8 Arrow buttons ↑ ↓
9 Enter button
10 Esc button
11 Arrow buttons ← →
12 Fine filter
13 Suction/pressure hose
14 Flush supply
15 Flush drain
16 Disinfection and cleaning unit supply REMS V-Jet TW or REMS V-Jet H
17 Pressure limiting valve
18 Non-return valve
19 Disinfection and cleaning unit drain REMS V-Jet TW or REMS V-Jet H
20 Flow head
21 Bottle (container) with dosing solution
22 Output pressure test with compressed air, compressed air pump
23 Compressed air hose
24 Supply pressure test with water
25 Drain pressure test with water
26 High-pressure hose
27 Water drain pressure relief
28 Compressed air tools connection
29 Emergency stop button compressor
30 Pressure gauge compressed air tank
31 Compressed air tools pressure setting
32 Compressed air tools pressure gauge
33 USB connection
34 Condensation screw plug
35 Compressed air tank
36 Operating panel
37 Protective hood
38 Connection hose compressor/water connections
39 Control lamp PRCD
40 Printer
41 LED
42 Paper tray rail
43 On/Off button, paper feed
44 Charger
45 USB lead
General Power Tool Safety Warnings
WARNING
Read all the safety notes, instructions, illustrations and technical data which
come with this power tool. Failure to heed the following instructions can lead to
electric shock, fire and/or severe injuries.
Keep all safety notes and instructions for the future.
The term "power tool" used in the safety notes refers to mains operated power tools
(with power cable).
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the pres-
ence of flammable liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions
can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools. Unmod­
ified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric shock
if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
d) Do not misuse the connecting cable to carry or hang up the power tool or
16
to pull the plug out of the socket. Keep the connecting cable away from
heat, oil, sharp edges or moving tool parts. Damaged or knotted cables
increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of
electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating
a power tool. Do not use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non­skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source, picking up or carrying the tool. Carrying power
tools with your finger on the switch or energising power tools that have the switch
on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
f) Wear suitable clothing. Do not wear loose clothing or jewellery. Keep hair
and clothing clear of moving parts. Loose clothing, jewellery or long hair can
get caught in moving parts.
h) Do not take your safety for granted and ignore the safety rules for power
tools even if you are very familiar with the power tool after frequent use.
Careless handling can lead to severe injury within split seconds.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power
tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source before making any adjustments,
changing accessories, or storing power tools. Such preventive safety meas­
ures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power
tool. Power tools are dangerous in the hands of untrained users.
e) Look after the power tools and accessories carefully. Check for misalignment
or binding of moving parts, breakage of parts and any other condition that
may affect the power tool's operation. If damaged, have the power tool re-
paired before use. Many accidents are caused by poorly maintained power tools.
f) Use power tools, accessories and insert tools etc. according to these
instructions. Take the working conditions and activity being performed into
consideration. The use of power tools for purposes for which they are not intended
can lead to dangerous situations.
g) Keep handles and gripping surfaces dry, clean and free from oil and grease.
Slippery handles and gripping surfaces prevent safe handling and control of the
power tool in unforeseeable situations.
5) Service
a) Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power tool
is maintained.
Safety notes for the electronic flushing and
pressure testing unit with compressor
WARNING
Read all the safety notes, instructions, illustrations and technical data which
come with this power tool. Failure to heed the following instructions can lead to
electric shock, fire and/or severe injuries.
Keep all safety notes and instructions for the future.
● Never use the power tool without the PRCD fault current circuit breaker
included. The use of a fault current circuit breaker reduces the risk of electric
shock.
● The power tool develops very high pressures, in applications with compressed
air of up to 1 MPa/10 bar/145 psi and in applications with water of up to
1.8 MPa/18 bar/261 psi. So be very careful. Never let the power tool operate
unattended. Keep third parties away from the work area when working with the
electrical device.
● Do not use the power tool if it is damaged. There is a danger of accident.
● The power tool is not intended/suitable for permanent connection to the
installation. Disconnect all hoses from the installation after completing the work.
Electrical devices can cause hazards which lead to material damage or injury
when left unattended.
● Examine the high-pressure hoses for damage every time before using.
Damaged high­pressure hoses can burst and cause injury.
● Only use original high-pressure hoses, fittings and couplings for the power
tool. This ensures that the safety of the device is maintained.
