Instructions for installation and use
PRO D2i / PRO D2i white / PRO D3i / PRO D3i white
Same functional scope as the Pro D2 / Pro D2 white and the PRO D3 / PRO D3
white, with the following additional features:
● Auxiliary output
Either for dimming (up to 500 W), switching (up to 3.5 kW) or regulating the
sauna cabin temperature via the additional output.
The additional output has no overheat cut-out. For this reason, only intrinsically
safe devices should be operated using the additional output.
– If infrared heaters are connected to the additional output, they must have
an overheat cut-out. We recommend using the following infrared heaters:
● 1-027-780 / DIR-350-R, 1-027-845 / WIR-350-R, 1-027-781 / DIR-500-R,
1-027-846 / WIR-500-R, 1-027-782 / DIR-750-R, 1-027-847 / WIR-750-R,
1-027-779 / DIR-1300-R
● 1-027-785 / ECO-350-R, 1-027-784 / ECO-350-G, 1-027-788 / ECO-
500-R, 1-027-787 / ECO-500-G, 1-027-790 / ECO-750-R
– If one of the following infrared heating plates is connected to an additional
output, the foil sensor 1-014-445 / P-ISX-FF must be used and activated
on the technician menu (see "Activating/deactivating the foil sensor
(Pro D2i / Pro D3i only)" on page 32):
● 1-028-348 / IR-WP-100, 1-028-343 / IR-WP-175, 1-028-784 / IR-WP-390,
1-028-938 / IR-WP-510
● 1-028-149 / IR-WPHL-100, 1-028-941 / IR-WPHL-175, 1-028-601 / IR-
WPHL-390, 1-027-885 / IR-WPHL-510
Pro D2 (white)
Pro D2i (white)
Pro D3 (white)
Pro D3i (white)
Fig.1 Overview of Pro D functions
X X X
X X X X
X X X X
X X X X X
