Installation instructions, only for experts
Remote start mode
Function selection switch 7 is used to select start of sauna/vaporizer operation
or user program 1/2.
● Function selection switch 7 is set to the OFF position as standard. The start
of sauna/vaporizer operation is activated. Terminal "S" starts the sauna op-
eration and terminal "C" starts the vaporizer operation.
● If you wish to activate user program 1/2, place the function selection switch 7
in the ON position. Terminal "S" starts user program 1 and terminal "C" starts
user program 2.
Connection: see "5.12. Remote start" on page 26
Temperature/humidity display (actual/set value)
Using function selection switch 8, you can select whether the actual value is
displayed or the set level continues to be displayed after entering the setting
(temperature, humidity).
● Function selection switch 8 is set to the OFF position as standard. The display
of the actual values is activated.
● If you wish to activate the set values, place the function selection switch 8 in
the ON position.

8.2. Settings in the technician menu

Opening the technician menu
Additional settings can be made in the technician menu. To access the technician
menu, perform the following steps:
1. Switch on the power unit. Press the On/Off button F.
► The sauna control unit is in stand-by mode.
► The display 1 on the control panel shows "---".
2. Press the plus B, minus C and On/Off A buttons simultaneously.
► The display 1 on the control panel shows "SEt"
► The temperature symbol 5 and the user program symbol 4 light up.
3. Press the mode button D to access the setting you wish to change.
Saving settings and exiting the technician menu
1. Press the On/Off button A for about 3 seconds.
Then switch the power unit off for about 10 seconds. (see "Switching off the
power unit" on page 53).
p. 31/31
EN
