3. Set the fuel valve (11) to the "OFF" position.
4. Disconnect the power consumers from the product.
NOTE
You can only remove the ignition key when the
"STOP" position is selected.
9.5 Overload indicator (24) (Fig. 11)
The overload protection becomes active if the power
consumption is too high and switches off the 230 V ~-
sockets (9).
1. Switch off the product, as described in section 9.4.
2. Disconnect the power consumers from the product.
9.6 Oil warning indicator (23) (Fig.
11)
The indicator activates when the oil level is too low and
deactivates as soon as the oil level is sufficient.
9.7 Automatic oil cut-off (Fig. 11)
The automatic oil cut-off system responds when there
is too little engine oil. The oil warning indicator (23)
starts flashing when there is too little oil in the engine.
The indicator lamp starts to light up when the oil quanti-
ty has not reached the safety quantity. The engine
switches itself off after a short time. It is not possible to
start the engine until the engine oil has been filled (see
chapter 8.3).
9.8 Energy saving switch (ECO) (13)
(Fig. 1)
ATTENTION
The energy-saving switch (ECO) is not suitable for
applications in which a consumer requires a lot of en-
ergy very quickly.
The energy-saving switch (ECO) (13) can be used to
limit fuel consumption and reduce noise when less
power is needed.
1. To do so, set the energy-saving switch (ECO) (13)
to "1". The power generating unit now regulates the
speed in accordance with the required power.
The energy saving switch (ECO) (13) must be set to "0"
when electrical devices that require a high starting cur-
rent are connected, for example a compressor. The en-
ergy saving switch (ECO) (13) must also be set to "0"
initially when the power generating unit is started.
9.9 "RESET" button (15) (Fig. 1)
If the overload protection has been triggered and the
overload indicator (24) lights up red, the "RESET" but-
ton (15) can restore the output power of the power gen-
erating unit. It is then not necessary to restart the en-
gine.
36 | GB
1. Press and hold the "RESET" button (15) for 1 sec-
ond until the light (red) is extinguished and the oper-
ation indicator (25) (green) illuminates.
If the overload protection has not tripped, the "RESET"
button (15) has no effect.
9.10 Display button (26) (Fig. 11)
The display (16) is active when the engine is running.
You can use the display button (26) to alternate be-
tween displaying the following data:
• Engine speed
• Operating hours
• Output power
The display (16) switches itself off after approx. 20 sec-
onds if not used.
9.11 Charging external devices
(Fig. 1, 3)
DANGER
Danger due to incorrect charging.
1. Plug the adapter cable with 12 V terminals (E) into
the 12 V DC connection (8) provided for this.
10 Cleaning
• Before carrying out any cleaning or maintenance
work, switch off the engine and remove the ignition
key from the ignition lock. In addition, remove the
spark plug connector from the spark plug.
ATTENTION
Danger of burning!
Wait until the product has cooled down before per-
forming cleaning or maintenance work.
ATTENTION
Take any contaminated maintenance material and
operating materials to a collection point designated
for this purpose.
10.1 Cleaning
• Keep protective devices, air vents and the motor
housing as free of dust and dirt as possible. Rub the
product clean with a clean cloth or blow it off with
compressed air at low pressure. We recommend
that you clean the product directly after every use.
• Clean the product at regular intervals using a damp
cloth and a little soft soap. Do not use any cleaning
products or solvents; they could attack the plastic
parts of the product. Make sure that no water can
penetrate the product interior.
