1 Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer
We hope your new product brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability for
damage to the product or caused by the product arising
from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised
specialists
• Installing and replacing non-original spare parts
• Improper use
Note:
Read the whole text of the operating manual before as-
sembly and commissioning.
This operating manual should help you to familiarise
yourself with your product and to use it for its intended
purpose.
The operating manual includes important instructions
for the safe, proper and economic operation of the
product, for avoiding danger, for minimising repair costs
and downtimes and for increasing the reliability and ex-
tending the service life of the product.
In addition to the safety instructions in this operating
manual, you must also observe the regulations applica-
ble to the operation of the product in your country.
Keep the operating manual package with the power tool
at all times and store it in a plastic cover to protect it
from dirt and moisture. They must be read and carefully
observed by all operating personnel before starting the
work.
The product may only be used by personnel who have
been trained to use it and who have been instructed
with respect to the associated hazards.
In addition to the safety instructions in this operating
manual and the separate regulations of your country,
the generally recognised technical rules relating to the
operation of such products must also be observed.
We accept no liability for accidents or damage that oc-
cur due to a failure to observe this manual and the
safety instructions.
2 Product description (Fig. 1-16)
1. Sight glass for fuel
2. Fuel filler cap
3. Pull starter
4. Cover
5. Wheels
6. Earthing screw
7. 12 V DC. Circuit breaker
8. 12 V DC connection
9. 230 V ~ socket (2x)
10. Battery compartment cover
11. Fuel valve
12. Folding transport handle
13. Energy-saving switch (ECO)
14. Ignition lock
15. "RESET" button
16. Display
17. Battery
17a. Battery connection cable
17b. Engine connection cable
17c. Battery bracket
18. Pairing button
19. Oil dipstick
20. Fuel filter insert
21. Fuel tank
22. Handle
23. Oil warning indicator
24. Overload display
25. Operating display
26. Display button
27. Engine cover
28. Spark plug
29. Spark plug connector
30. Oil drain screw
31. Oil drain plug
32. Air filter cover
32a. Wing nut
32b. Washer
33. Air filter
3 Scope of delivery
Item Quanti-
ty
A 1 x
B 2 x
C 2 x
D 1 x
E 1 x
F 1 x
G 1 x
1 x
4 Proper use
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or injuries
of any type resulting from this.
An element of the intended use is also the observance
of the safety instructions, as well as the assembly in-
structions and operating information in the operating
manual.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about
potential dangers.
www.scheppach.com
Designation
Power generator
Ignition key
Radio remote control
Spark plug wrench
Adapter cable with 12V terminals
Phillips screwdriver
Oil filler bottle
Operating manual
