Alde Compact 3030 Installationsanleitung Seite 52

11. Starting the heating system for the first time
1. Start the heating system by pressing the ON/OFF button on the control panel. (Fig.25 item 1)
When the heating system and control panel are on, a green diode is lit on the ON/OFF button.
2. Select language. This option is always shown when the panel is first started.
3. Press the Configure button to go to System configuration. You can always reach this menu by
pressing the menu button on the Alde Control Panel and scrolling until the System Configuration
option arrives.
The relevant function is highlighted if connected:
Pump, 12 V pump, Single zone
Booster fan
Underfloor heating, 12 V pump
for underfloor heating
Engine pre-heat, engine heater. Heat the
engine using the Alde heating system.
Extra hot water tank/Alde Flow, for
increased hot water capacity and
continuous hot water. (Not 3030 Plus)
Fig. 24
5. Dual zone system
• Browse through System configuration, activate any accessories/functions fitted using their
respective menus. (Fig. 30)
• Go back using the Back arrow in the left corner, and select "Done".
1
Fig. 25. 1 ZONE
- Switching a pump to continuous operation may entail impaired hot water operation.
52
Fig. 26. 1 ZONE
DuoControl, Bottle Switch
EisEx (Defroster)
Remote Control
2 zone mode
Alde AquaClear
