Alde Compact 3030 Installationsanleitung Seite 43

5.8 Alternative locations for expansion vessels, dual-zone system
Dual zone
Circulation pumps
Fig. 13, Dual zone system with flow through expansion tank
Dual zone
Circulation pumps
Fig. 14, Dual zone system with riser to expansion tank
Drain through floor
Non-return valves
Zone 1
Drain through floor
Non-return valves
Zone 1
Alternative placement
of expansion vessels
Zone 2
Alternative placement
of expansion vessels
Glycol in
Air out
Zone 2
Alternative placement
of expansion vessels
NOTICE
Not for 3030 Plus
Alternative placement
of expansion vessels
NOTICE
Not for 3030 Plus
Air out
Glycol in
