78 | ORBEA
COMPOSANTS DU CIRCUIT ÉLECTRIQUE
ORBEA RS ET SHIMANO
COMPO SA N TS S H I M A N O*
1 MOTEUR ÉLECTRIQUE SHIMANO EP8 RS
CÂBLE SHIMANO STEPS-DI2 EW-SD300
2
3
4
5 ADAPTATEUR SHIMANO EW-AD305 Câble
EW-SD50 / EW-SD300
6 BOÎTIER DE JONCTION-A SHIMANO EW-EN100
7
8
9 COMMANDE AU GUIDON SHIMANO
SW-EM800-L Pas de câble
10 COMMANDE AU GUIDON SHIMANO
11 CAPTEUR DE VITESSE SHIMANO EW-SS301.
* Les composants Shimano sont disponibles via un revendeur Shimano.
M AN UE L TE CH NI QUE
COMPOSANTS ORBEA RS
12 BATTERIE INTERNE ORBEA RS
13 BATTERIE ORBEA RS RANGE
14 CHARGEUR SMART CHARGER
15 CACHE DE PORT DE CHARGE
avec vis
FAISCEAU DE CÂBLES BATTERIE
16
RS / POINT DE CHARGE / COM-
mm
17 MINI BOUTON ON/OFF RS avec
18
AIMANT DE CAPTEUR DE
19
B LU E PA P E R R I SE · HYDRO 2022
REAR CENTERLOCK DISC BRAKE
ROTORS COMPATIBILITY
RÉF
Orbea models originally assembled with Centerlock
wheels and rotors use a Shimano RT-EM600 rear Center-
lock rotor, which integrates the speed sensor magnet
within the rotor spider.
If it is necessary to replace the rear Centerlock rotor, or if
Y041
Centerlock wheels are to be installed on models originally
assembled with 6-bolt wheels, Rise Hydro 2022 is only
compatible with the following rear disc brake rotors with
· Shimano RT-EM600, RT-EM800, RT-EM900
· Shimano RT-EM810, RT-EM910
Shimano rear disc brake rotors with the magnet integrated
in the Centerlock lockring are not compatible with Rise
Hydro 2022, since these rotors are designed for a different
speed sensor model, and therefore will not provide a rear
wheel reading to the system.
COMPATIBLE
OPTIONS
MAGNET
ORBEA | 79
Rise Hydro 2022 is not compatible with the
This magnet, which is assembled onto the
Centerlock lockring, does not provide
enough clearance between the magnet and
the frame, and will damage the frame and/
or the speed sensor.
Damages produced from installing this mag-
net or rear rotor models different from the
warranty terms.
NOT COMPATIBLE
OPTIONS
MAGNET
ORBEA
X095
