80 | ORBEA

EP8 MOTOR ASSEMBLY

Always follow the recommended
24.3
24.4
24.5
24.1 6
12 N.m
24.5
6
24.2
12 N.m
6
24.2
12 N.m
24 EP 8 R S M OTO R F I X I N G K I T R I S E H Y DR O 22
ART Nº: XA87
Front motor spacer 8x22x12
O-ring 10x1
TECHNICAL MANUAL
6
24.1
12 N.m
24.5
6
24.2
12 N.m
24.4
24.3
24.5
6
24.2
12 N.m
24.5
24.6
24.5
QTY.
2
4
2
2
6
1
B LUE PAP ER R I SE · HYDRO 2022
I N T E RN A L BAT T E RY
R S 5 40W H
Read the maintenance, use, charge and
storage indications of the RS batteries in the
Maintenance and Electric Components Use
Also read how to charge, turn on and check
the battery level in the Use of Rise section of
For more important information about the RS
batteries, read the Relevant Information about
RS INTERNAL BATTERY TECHNICAL SPECIFICATIONS
VOLTAGE
CAPACITY
WEIGHT
CELLS
CHARGING TIME 100% (4A)
With RS Smart Charger
CHARGING TIME 80% (4A)
With RS Smart Charger
ASSEMBLY
CONNECTION
WATERPROOFNESS
CERTIFICATIONS
COMPATIBILITY
ORBEA | 81
540 Wh
3 hours
Harness cable to motor, charging port and On/Off button
IP66
ISO13849 > ISO13849-1:2015
IEC62133 > IEC62133:2017
Not compatible with Rise Carbon 2021-2022
E N
