78 | ORBEA
ORBEA RS AND SHIMANO
ELECTRIC SYSTEM COMPONENTS
SH I MANO COMP ON EN TS *
1 SHIMANO EP8 RS MOTOR
2 CABLE SHIMANO STEPS-DI2 EW-SD300 1200mm
3 CABLE SHIMANO STEPS-DI2 EW-SD300 400mm
4 CABLE SHIMANO STEPS-DI2 EW-SD50 400mm
5 ADAPTER SHIMANO EW-AD305 Cable
EW-SD50 / EW-SD300
6
7
8
9
No cable
10
300mm cable
11
TECHNICAL MANUAL
ORBEA RS COMPONENTS ART Nº
12
13 ORBEA RS RANGE EXTENDER
14 ORBEA RS SMART CHARGER
2A-4A EU/US/UK/AUS
15
with screws
16
CHARGE POINT/SWITCH
(205/150/80mm)
17 RS MINI SWITCH ON/OFF
18 RS RANGE EXTENDER CABLE
2022 225mm
SPEED SENSOR MAGNET ORBEA
19
6-BOLT
B LU E PA P E R R I SE · HYDRO 2022
REAR CENTERLOCK DISC BRAKE
ROTORS COMPATIBILITY
Orbea models originally assembled with Centerlock
wheels and rotors use a Shimano RT-EM600 rear Center-
XA81
lock rotor, which integrates the speed sensor magnet
If it is necessary to replace the rear Centerlock rotor, or if
Centerlock wheels are to be installed on models originally
assembled with 6-bolt wheels, Rise Hydro 2022 is only
compatible with the following rear disc brake rotors with
the magnet integrated within the rotor spider:
XA82
· Shimano RT-EM600, RT-EM800, RT-EM900
· Shimano RT-EM810, RT-EM910
XA83
Shimano rear disc brake rotors with the magnet integrated
in the Centerlock lockring are not compatible with Rise
Hydro 2022, since these rotors are designed for a different
speed sensor model, and therefore will not provide a rear
XA84
XA85
XA86
COMPATIBLE
OPTIONS
X240
MAGNET
ORBEA | 79
Rise Hydro 2022 is not compatible with the
This magnet, which is assembled onto the
Centerlock lockring, does not provide
enough clearance between the magnet and
the frame, and will damage the frame and/
Damages produced from installing this mag-
net or rear rotor models different from the
NOT COMPATIBLE
OPTIONS
MAGNET
ORBEA
X095
EN
