96 | ORBEA
ADAPTATIVE
CHARGING CURRENT
The Smart Charger RS recognizes what battery it is con-
nected to (internal battery 540Wh or Range Extender
The charging current of the internal battery is 4A
The Smart Charger charges the internal battery to up to
The charging current of the Range Extender is 2A

USING THE RS SMART CHARGER

Read the charging the RS batteries in the Use
of Rise H section of this manual to know how
to use the Smart Charger to charge the inter-
MEANING OF THE SMART CHARGER LED
LED
TECHNICAL MANUAL
3 2 SMART CHARGER ORBEA RS 4A-2A 42V
Mains cable options EU, US, UK, AUS
ART Nº: XA82
Mains cable options EU, US, UK, AUS
To protect the charger and the batteries, the
RS Smart Charger disables itself once the
want to charge the internal battery or the
charger from the mains outlet and plug it
you have not disconnected the charger from
the outlet between charges, the charger may
BEHAVIOUR STATUS
Blinking blue LED Charger connected to an outlet but
not connected to the battery
Blue LED fades in and out Charger charging
cyclically the battery
Still blue LED Charge completed
Still red LED
troubleshooting table below
B LU E PA P E R R I SE · HY DR O 2022
RS SMART CHARGER
TROUBLESHOOTING PROCEDURE
LED
QTY.
1
RS SMART CHARGER.
USE WARNINGS
Consult the Relevant Information about the RS Batteries to
read more about the recommended use and maintenance
POSSIBLE ERROR SOLUTION
(Follow solutions
in descending order)
Current too high
· Inspect the connector and the charging port for debris, humidity
Shortcircuit
· Inspect the connector and the charging port for debris, humidity
· Wait until the charger temperature is within the recommended
Temperature too high
The time the charger has been connected to the battery an/or
Standby
communication
ORBEA | 97
EN
