24 | ORBEA
Disconnect the charger from the bicycle´s charging port
While the charger is connected to Rise, the bicycle cannot
If you want to know the exact internal battery level at a
given time, disconnect the charger from the bicycle, turn
Rise on, and connect it to your Garmin unit with Orbea
On assemblies with the Shimano displays, disconnect the
charger and power the bicycle on to see the current bat-
Avoid leaving the charger connected to the bike continu-
ously for extended periods of time and charge your bicycle
or battery in a place where you have visual access to it so
the charger can be disconnected if any anomaly is detect-
The RS Smart Charger has been designed to stop charg-
ing the battery when the charge is completed to avoid
However, it is recommended to supervise the charge to
The lithium-ion batteries are sensitive to temperature dur-
TECHNICAL MANUAL
To protect the charger and the batteries, the
RS Smart Charger disables itself once the
want to charge the internal battery or the
charger from the mains outlet and plug it
you have not disconnected the charger from
the outlet between charges, the charger may
RS RANGE EXTENDER BATTERY.
The Rise Hydro Smart Charger is not compat-
ible with the Rise Carbon 2021-2022 internal
The Rise Carbon 2021-2022 charger is not
compatible with the Rise Hydro internal bat-
To charge the Range Extender, plug the RS charger to the
ed to the charger, the LED on the charger´s body will blink
B LUE PAP ER R I SE · HYDRO 2022
Disconnect the Range Extender connection cable to the
bicycle charging port (in case it is connected) by turning
Connect the charger to the Range Extender correctly
aligning the connector pins with those of the Range Ex-
blue for 2 seconds and then it will start fading in and out
When the battery is fully charged, the charger´s body LED
100%
-
While the Range Extender is being charged, the charge
ORBEA | 25
When the battery is fully charged, disconnect the charger
from the charging port by carefully pulling from the char-
If you are going to use the Range Extender on the bicycle,
connect the Range Extender cable to the Range Extender
and the bicycle charging port with the safety tabs open
and, once the cable is correctly connected, turn the tabs
· Avoid leaving the charger connected to the bike conti-
nuously for extended periods of time and charge your
bicycle or battery in a place where you have visual
access to it so the charger can be disconnected if any
anomaly is detected, such as smoke, unusual smells
The RS Smart Charger has been designed to stop char-
ging the battery when the charge is completed to avoid
recommended to supervise the charge to avoid damages
