102 | ORBEA
CONNECTION OF SC-EM800
DISPLAY ASSEMBLIES
On models using the SC-EM800 display, it is possible to use one of the free display connectors to connect the SM-
SC-EM800
Shimano
EW-SD300 cable

CONNECTION OF EW-EN100 JUNCTION ASSEMBLIES

SW-EM7000 L
EW-EN100
TECHNICAL MANUAL
EW-AD305
Shimano EW-SD50
PC-Link cable
Shimano SM-PCE02
SM-JC41
Shimano EW-SD50
PC-Link cable
Shimano SM-PCE02
B LUE PAP ER R I SE · HYDRO 2022
CONNECTION OF SC-E7000
DISPLAY ASSEMBLIES
To connect models using the SC-E7000 display, it is pos-
sible to use one of the free display connectors to directly
SC-E7000
ORBEA RS BATTERY
IN ETUBE PROFESSIONAL
The Orbea RS battery is visible in Etube Professional when
connecting the Rise EP8 RS system using the Shimano
With the PCE02 tool you can also access releveant infor-
mation about the battery in the Maintenance tab, like the
ORBEA | 103
E N
Shimano EW-SD50
PC-Link cable
Shimano SM-PCE02
The Orbea RS 540Wh internal battery is not
there is a problem in the Rise H electric sys-
tem, use Etube Professional to rule out that
the problem does not come from other of the
Contact Shimano to provide them with a
informs you that the problem comes from
the internal battery, contact Orbea through a
