Ultrasonic Unit SonicWeld Rx®
Instructions for Use

6 Maintenance

6.1

Troubleshooting

6.1.1

Displays

Message displayed
Power Supply Error
Temperature Gauge Defect
Generator Over Temperature
Device Error
Ultrasound Error
1. Release handpiece!
2. Press on/standby!
Welding Time > 60s
1. Tighten sonotrode!
2. Press on/standby!
System error
Revision 04
Cause
Generator error or fault.
Generator problem (during welding
process).
System overload (sonotrode tip
stuck/jammed, excessive pressure).
Maximum welding time of 60 s
exceeded.
Sonotrode seated too loosely.
Monitoring of all important program
modules.
Remedy
Disconnect the unit from the power
supply, and then reconnect it.
If the problem persists, return unit to
manufacturer, see section 2.1, page 55.
Acknowledge by pressing the
On/Standby switch.
If the problem persists, disconnect the
unit from the supply.
Acknowledge by pressing the
On/Standby switch, then clear the
handpiece problem and operate the
activation pushbutton again
After a cooling-down time of 5 s, the unit
is ready for use again.
Tighten sonotrode with wrench (12,
front fold-out page), and acknowledge
error.
Disconnect the unit from the power
supply, and then reconnect it.
If the problem persists, return unit to
manufacturer, see section 2.1, page 55.
77
