Connection
Electrical connection of the
fan
assembled at the factory
(24 V DC)
Table 9: Cable connections
Cable requirements
Terminals are intended for rigid and flexible conductors with or without ferrules.
If flexible cables are used, the use of ferrules is recommended.
Connection
Electrical mains connec-
tion
SSM
SBM
Digital input EXT. OFF
Digital input EXT. MIN/
EXT. MAX
Analogue input 1
Analogue input 2
Analogue input 3
Analogue input 4
Wilo Net
CIF module
Table 10: Cable requirements
*
Cable length ≥ 2 m: use shielded cables.
**
When using ferrules, the maximum cross-section at the terminals of the communication in-
terfaces is reduced to 0.25 ... 1 mm².
In order to comply with electromagnetic compatibility standards, the following cables must
always be shielded:
• Cable for EXT. OFF/ MIN/ MAX at digital inputs
• Temperature sensors at analogue inputs
• External control cable sensors at analogue inputs
• Differential pressure sensor (DPS) at analogue inputs, if installed on-site
• Twin-head pump cable with two single pumps in the Y-piece (bus communication)
• CIF module to the building automation (bus communication)
The shield is connected to the cable bushing on the electronic module. See Fig. 24.

Terminal connections

Terminal connections for all cable connections in the electronic module correspond to push-
in technology. They can be opened with a screwdriver type slot SFZ 1 – 0.6 x 0.6 mm. Excep-
tion: Wilo-Smart Connect Module BT.
Length of cable to strip
The stripping length of the cables for the terminal connection is 8.5 mm ... 9.5 mm.
Installation and operating instructions • Wilo-Stratos GIGA2.0-I, Wilo-Stratos GIGA2.0-D • Ed.02/2022-07
Threaded cable gland
Terminal cross-sec- Terminal cross-section
tion
in mm
2
in mm
Max.
Min.
≤ 4 kW: ≤ 4 kW:
4x1.5 4x4
> 4 kW: > 4 kW:
4x2.5 4x6
2x0.2 3x1.5 (1.0**)
changeover relay
2x0.2 3x1.5 (1.0**)
changeover relay
2x0.2 2x1.5 (1.0**)
2x0.2 2x1.5 (1.0**)
2x0.2 2x1.5 (1.0**)
2x0.2 2x1.5 (1.0**)
2x0.2 2x1.5 (1.0**)
2x0.2 2x1.5 (1.0**)
3x0.2 3x1.5 (1.0**)
3x0.2 3x1.5 (1.0**)
Cable Terminal
bushing no.
Fig. 18,
Item
7 4 (Fig. 19)
Cable
2
*
*
*
*
*
*
*
*
Shielded
Shielded
