Protocol TIM-EC outgoing
Byte Significance
0 Status byte
Zero setting (torque
and angle of rotation)
is only confirmed via
a brief pulse (10ms).
The following applies
for shunt: The bits
always represent the
actual status, which
may not correspond
to the specifications
1 Parameter set
2 Error status
measured values
TIM-EC
ETHERCAT® CONFIGURATION
Bit Values
0 0
1
1 0
1
2 0
1
3..7 0
0...6 0
1..32
33-62
63
7 0
1
0 0
1
1 0
1
2 0
1
Bit significance
No action
Zero setting torque active
No action
Zero setting angle of rotation
active
Shunt is off
Shunt is on
Reserved
Parameter set being
processed/edited
Parameter set selected and active
Not permitted/reserved
Factory setting is active
Parameter set unlocked
Parameter set locked by web
browser
No measured value error/Global
flag over all measurement
channels
Measured value error Md/N
Name: Global_Failure_Flag
Torque values TP 1 OK
Torque values TP 1 Faulty
Name: Torque_Failure_Flag1
Torque values TP 2 OK
Torque values TP 2 Faulty
Name: Torque_Failure_Flag2
