SCOPE OF DELIVERY

S
One TIM-EC torque interface module
S
Plug-in terminals for transducer connection and supply voltage (4 in total)
S
TIM-EC operating manual
4

APPLICATION

The TIM-EC module receives the digital data flow from the TMC interface, processes the
data and transfers the measured values (torque, speed, etc.) to the EtherCAT
The same applies to connecting frequency signals.
ized by an integrated web server that shows all the parameters in a web browser via an
Ethernet connection. The Ethernet connection can be automatically initialized via UPnP.
The IP address is set in the factory to 192.168.1.2.
This state can be restored by pressing and holding the Reset button for 10 s while turning
on the power supply.
8
The TIM-EC is set up and parameter­
®
interface.
