DVI to VGA Adapter (Supplied with Video Card)
•
Converts video from DVI to VGA.
IMAGE CAPTURE (FLUORO) CABLES
Fluoro Video cable
•
Used to attach the video capture board to a fluoro imaging device.
•
Two cables are available to support various imaging requirements: VGA to VGA and 5 BNC VGA Cable.
RF GENERATOR INTERFACE CABLES
The RF Generator Interface Cable is used to connect a Radio Frequency (RF) Ablation Generator to a COM port
of the LABSYSTEM™ computer. The cable is available in three lengths (25 foot, 50 foot, 100 foot) and can be
purchased as a standard RS-232C cable or as an RS-232C null modem cable.
The table below lists the RF Ablation generators currently supported by LABSYSTEM and the RF Generator
Interface cable required to connect each generator in this list to the LABSYSTEM computer.
BARD® RF Cardiac Ablation Generator
EP Technologies' EPT1000TC
EP Technologies' EPT1000XP
Boston Scientific Corp. Maestro 3000
Medtronics Atakr1/Atakr II
Osypka, HAT 300 Smart
St. Jude Medical IBI-1500 T9 and T11
*Stockert RF Generators (70 W and 100 W)
All trademarks or registered trademarks for the generators listed above are the property of their respective owners.
1
Product availability varies by country. Please check with your local Boston Scientific representative for availability.
2
LABSYSTEM PRO EP Recording System Getting Started Guide
17
18
(1,2)
1
1
1
1
1
DB9-DB9, serial, male/female, standard RS-232C
DB9-DB9, serial, male/female, standard RS-232C
DB9-DB9, serial, male/female, standard RS-232C
DB9-DB9, serial, male/female, standard RS-232C
DB9-DB9, serial, male/female, standard RS-232C
DB9-DB9, serial, male/female, standard RS-232C
DB9-DB9, serial, male/female, standard RS-232C
DB9-DB9, serial, female/female, null modem RS-232C
*Note: This cable must be connected to the male
connector on the Stockert EP Shuffle Global Port
labeled "PC".
1
15
