Power module

32 I/O box
1 Does not restrict the maximum number of 12 input/output modules. Cannot be used with the 32 I/O box.
AVENTICS | HF03/HF02 | 1987765493–BDL–001–AB
3.2.2 Power module
1)
The bus coupler's restricted output can, in some circumstances,
limit the number of outputs required. The power module
supplies power to additional output modules up to a maximum
total current of 12 A.
It is located between the input/output modules.
The power supply must be led via the POWER X10 connection on
the power module.
3.2.3 32 I/O box
32 input and output channels are available. Each of those
channels can be used as an input or an output.
The outputs can always be read back. That means that
a channel used as an output can then be That means that
a channel used as an output can then be "read" via the
simultaneously present input.
53
System architecture
