12. Service Standards
(3) Valve spring
Inspection item
3TNV82A(2-valve)
4TNV84,3TNV84(T), 4TNV88(2-valve)
Free length 4TNV84T(4-valve)
4TNV94L, 4TNV98(T),(4-valve)
4TNV106(T)(4-valve)
3TNV82A(2-valve)
4TNV84, 3TNV84(T), 4TNV88(2-valve)
Inclination 4TNV84T(4-valve)
4TNV94L, 4TNV98(T), (4-valve)
4TNV106(T)(4-valve)
(4) Rocker arm and shaft
Model
TNV82A to 88
4TNV94L/98(T)/106(T)
(5) Push rod
Inspection item
Bend
(R.1)
Inspection item
Arm shaft hole diameter
Shaft outside diameter
Clearance
Arm shaft hole diameter
Shaft outside diameter
Clearance
Standard Limit
Less than 0.03 0.03
Standard
44.4
42.0
37.4
39.7
50.6
-
-
-
-
-
Standard
16.000 to 16.020
15.966 to 15.984
0.016 to 0.054
18.500 to 18.520
18.470 to 18.490
0.010 to 0.050
mm
Reference page
4.2.5.(7)
188
mm
Reference
Limit
page
43.9
41.5
36.9
39.2
50.1
4.2.5.(4)
1.4
1.4
1.3
1.4
1.5
mm
Reference
Limit
page
16.07
15.94
0.13
4.2.5.(5)
18.57
18.44
0.13
