9.2.9 Service standards

Spring force N (kgf)
Brush
Standard / Limit height
Outside diameter
Commutator Deflection
Depth of insulation mica
Armature shaft diameter
Standard
Bearing on gear case side
dimensions
Sliding portion of pinion
Ball bearing Armature
Length L (pinion projection length)

Dust cover

Standard
Limit
Limit
Correction accuracy
Limit
Correction accuracy
Front
Rear
Gear shaft diameter
Hole diameter
Shaft diameter
Hole diameter
Front
Rear
175-1
9. Starting Motor
l
31.4 (3.2)
18/6
37
36
0.2
0.05
0.2
0.5 to 0.8
25
12
13.95 to 13.968
14.00 to 14.018
13.95 to 13.968
14.03 to 14.05
6905DDU
6001DDU
0.3 to 1.5
