1.3.3.8
1.3.3.9
1.3.3.10 Power Button
1.3.3.11 IV Pole
1.3.3.12 Power Cord Port
1.3.3.13 Handle
1.3.3.14 Accessory Basket
1.3.3.15 Cord Wrap
10
Fluent Pro Fluid Management System
inaccurate fluid deficit value, causing risk to patient safety.
Wheels
The four wheels located on the bottom of the Fluent Pro Fluid Management System enable
movement and positioning of the Fluent Pro Fluid Management System.
Wheel Lock
A wheel lock is available on each of the four wheels. For details on using the wheel locks,
see Instructions provided in Section 2.
The Power button is located on the top of the Fluent Pro Fluid Management System.
Pole located next to the Touchscreen Monitor that contains two Fluid Bag Hooks.
The Power Cord Port is located on the rear of the Fluent Pro Fluid Management System.
The Power Cord attaches to the Power Cord Port. When the system is not in use, wrap the
Power Cord around the Cord Wrap on the rear of the system.
The 360° Handle is accessible from all directions and allows for the system to be moved
easily.
Figure 8: 360° Handle
Caution!
Only use the Handle to move or position the Fluent Pro Fluid Management System. Do not
pull or push the system with the IV pole or Touchscreen Monitor.
The Accessory Basket hangs on the rear of the Fluent Pro Fluid Management System. It is
used to store accessories such as Waste Bags, Scope Seals and Tissue Traps. Do not
place heavy items in the Accessory Basket. The maximum recommended weight is ten (10)
pounds.
Feature located on the rear of the Fluent Pro Fluid Management System to allow cord to be
wrapped and stored when not in use.
