Aquatec® Ocean Ergo / Ocean Ergo XL / Aquatec® Ocean 24" Ergo / Ocean 24" Ergo XL
4 Setup
4.1 Safety Information
WARNING!
— Check the parts for transport damage before
commissioning and contact your provider if
required.
— Ensure during assembly that the parts are
positioned correctly with respect to one another.
— Self-locking screws/nuts or thread-locking
adhesive are used for several connections. If
these are loosened, they must be replaced by
new self-locking screws/nuts or they must be
secured using new thread-locking adhesive.
CAUTION!
Risk of Pinching
— Take care during assembly.
4.2 Safety Information for Transport
The product can be dismantled for transport into the
parts of the scope of delivery, see chapter 3.1 Main
Parts of the Product, 8.
1. Disassemble the product: Refer to chapter 4.3 Assembling
the Product, 10 by following the assembly steps in reverse
order.
10
NOTICE!
Risk of Damage to the Product
— Transport the product in a dry area.
— Do not expose the product to direct sunlight.
— Refer to the storage and shipping conditions in
chapter Environmental Parameters in 9 Technical
Data, 26.
NOTICE!
— Self-locking screws / nuts or thread-locking
adhesive are used for several connections. If
these are loosened, they must be replaced by
new self-locking screws / nuts or they must be
secured using new thread-locking adhesive.
4.3 Assembling the Product
This section describes the assembly. Disassembly takes place in
the reverse order.
The armrest height, footrest height, footrest angle, heel
strap, tension of backrest cover and accessories /
options must be adjusted to optimally fit the user.
