Symbol Glossary
Symbol Title Symbol
Manufacturer
Authorized
Representative
in European
Community /
European Union
Date of
manufacture
Catalogue number
Serial number
Keep dry
Consult instructions
for use or consult
electronic
instructions for use
Caution
Medical Device
Unique device
identifier
Importer
No Free Hosing
CE Mark
Description and Reference
Indicates the medical
device manufacturer.
Source: ISO 15223, 5.1.1
Indicates the authorized
representative in the
European Community /
European Union. Source:
ISO 15223, 5.1.2, 2014/35/
EU, and/or 2014/30/EU
Indicates the date when
the medical device was
manufactured. Source:
ISO 15223, 5.1.3
Indicates the
manufacturer's catalogue
number so that the medical
device can b e identified.
Source : ISO 15223, 5.1.6
Indicates the
manufacturer's serial
number so that a specific
medical device can be
identified. Source: ISO
15223, 5.1 .7
Indicates a medical device
that needs to be protected
from moisture. Source:
ISO 15223, 5.3.4
Indicates the need for
the user to consult the
instructions for use.
Source: ISO 15223, 5.4.3
Indicates that caution is
necessary when operating
the device or control close
to where the symbol is
placed, or that the current
situation needs operator
awareness or operator
action in order t o avoid
undesirable consequences.
Source: ISO 15223, 5.4.4
Indicates the i tem is a
medical device. Source:
ISO 15223, 5.7.7
Indicates a carrier that
contains unique device
identifier information.
Source: ISO 15223, 5.7.10
Indicates the entity
importing the medical
device into the locale.
Source: ISO 15223, 5.1.8
Safety sign indicating no
free hosing
Indicates conformity to
all applicable European
Union Regulations and
Directives with notified
body involvement.
Rx Only
Maximum safe
working load
15
UL Classified
Green Dot
Refer to instruction
manual/booklet
Protective earth
(ground)
Equipotentiality
Fuse
Recycle electronic
equipment
Type BF applied
part
For more in formation see, HCBGregulatory.3M.com
Indicates that U.S. Federal
Law restricts this device to
sale by or on the order of
a healthcare professional.
21 Code of Federal
Regulations (CFR) sec.
801.109(b)(1)
Indicates the maximum
safe working load in less
than the number reported.
Indicates product was
evaluated and Listed by UL
for the USA and Canada.
Indicates a financial
contribution to national
packaging recovery
company per European
Directive No. 94/62 and
corresponding national
law. Packaging Recovery
Organization Europe.
To signify that the
instruction manual/booklet
must be read. ISO
7010-M002
To identify any terminal
which is intended for
connection to an external
conductor for protection
against electric shock
in case of a fault, or the
terminal of a protective
earth (ground) electrode.
Source: IEC 60417, 5019
To identify the terminals
which, when connected
together, bring the various
parts of an equipment or
of a system to the same
potential, not necessarily
being the earth (ground)
potential. Source: IEC
60417-5021
Indicates a replaceable fuse
DO NOT throw this unit into
a municipal trash bin when
this unit has reached the
end of its lifetime. Please
recycle. Source: Directive
2012/19/EC on waste
electrical and electronic
equipment (WEEE)
To identify a type BF
applied part complying with
IEC 60601-1. Source: IEC
60417-5333
