6 Commissioning
Operating mode
"Single" process
temperature
98
DEVICE_ID = 452B481200_XXXXXX041C4
452B48 = Endress+Hauser
1200 = TMT 165
XXXXXX041C4 = Device serial number (11 digit)

6.2.1 Initial commissioning

The following description allows step-by-step commissioning of the measuring device
and all the necessary configuration for the FOUNDATION Fieldbus:
1. Switch on the Measuring Device.
2. Note the DEVICE_ID on the device nameplate.
3. Open the configuration program.
4. Load the device description file or CFF file into the host system or into the configu-
ration program. The first time it is connected TMT 165 reports as follows:
FIELD DEV -XXXXXX041C4
5. Identify the field device using the DEVICE_ID that you noted down and assign the
desired field device tag name (PD_TAG) to the fieldbus device in question.
'Resource Block' configuration
6. Open the 'Resource Block'.
7. On delivery write protection is disabled so that you can access all the write param-
eters. Check this status via the parameter WRITE_LOCK:
– Write protection activated = LOCKED
– Write protection deactivated = NOT LOCKED
8. Enter the desired block name.
9. Set the operating mode in the parameter group MODE_BLK (parameter TARGET)
to AUTO.
'Transducer Block' configuration
10. Enter the desired block name.
11. Open the 'Transducer Block'.
12. Set the operator mode in the parameter group MODE_BLK (parameter TARGET) to
OOS, i.e. block 'Out of service'.
13. Now configure all device specific parameters for the temperature measurement.
Description
Measurement of one process
temperature in 2-, 3- or 4 wire
configuration.
FOUNDATION Fieldbus temperature transmitter
Parameter configuration
PRIMARY_VALUE_TYPE
Process temperature
SENSOR CONNECTION
Four wires
Three wires
Two wires
SENSOR_TYPE
Endress+Hauser
