Technical Data

10.1 Operation and system construction

Electronic measurement and conversion of input signals in industrial temperature
measurement.
®
The iTEMP FF TMT 165 temperature field transmitter is a 2-wire transmitter with dual
channel measurement input for resistance thermometers, in 2-, 3-, or 4-wire connection,
thermocouples, voltage transmitters and differential measurement. Applications are in
the measurement and control areas for process monitoring. The TMT 165 is set up using
®
the FF protocol combined with a process control software.

10.2 Input values

Temperature, Ohm, mV, differential measurement or two channel measurement.
The transmitter monitors various measurement ranges dependent on the sensor
connection and input signal.
Measurement Measurement
range (°C) range (F)
-20 to 250 -4 to 482
-50 to 270 -58 to 518
-200 to 850 -328 to 1562
-200 to 850 -328 to 1562
-200 to 450 -328 to 842
-200 to 600 -328 to 1112
-200 to 600 -328 to 1112
+100 to 1800 +212 to 3272
-100 to 1000 -148 to 1832
-150 to 750 -238 to 1382
-200 to 1350 -328 to 2462
-100 to 1300 -148 to 2372
0 to 1750 32 to 3182
0 to 1750 32 to 3182
-200 to 400 -328 to 752
-200 to 900 -328 to 1652
-200 to 600 -328 to 1112
Differential
Accuracy Measurement
(°C) range (°C)
±1.0 -270 to 270
±0.1 -320 to 320
±0.25 -1050 to 1050
±0.2 -1050 to 1050
±0.25 -650 to 650
±0.25 -850 to 850
±0.25 -800 to 800
±0.5 -1600 to 1600
±0.2 -1100 to 1100
±0.3 -900 to 900
±0.6 -1550 to 1550
±0.5 -1400 to 1400
±0.4 -1750 to 1750
±0.4 -1750 to 1750
±0.15 -600 to 600
±0.35 -1100 to 1100
±0.5 -800 to 800
10 Technical Data
Measurement Accu-
range (F) racy (°C)
-486 to 486 ±2.0
-576 to 576 ±0.2
-1890 to 1890 ±0.5
-1890 to 1890 ±0.4
-1170 to 1170 ±0.5
-1440 to 1440 ±0.5
-1440 to 1440 ±0.5
-3060 to 3060 ±1.0
-1980 to 1880 ±0.4
-1620 to 1620 ±0.6
-2790 to 2790 ±1.2
-2520 to 2520 ±1.0
-3150 to 3150 ±0.8
-3150 to 3150 ±0.8
-1080 to 1080 ±0.8
-1980 to 1980 ±0.7
-1440 to 1440 ±1.0
