FOUNDATION Fieldbus temperature transmitter
Index Parameter
25 HI_HI_PRI
28 HI_LIM
27 HI_PRI
Endress+Hauser
Analogue Input Function Block
Write access with
operating mode
(MODE_BLK)
AUTO - MAN - OOS Specifies the action taken when the upper alarm limit value (HI_HI_LIM) is
exceeded.
User input:
0
1
2
3-7
8-15
Factory default:
AUTO - MAN - OOS Entry of the alarm limit value for the upper pre alarm (HI_ALM). If the output
value OUT exceeds this limit value, then the alarm status parameter HI_ALM
is output.
User input:
Factory default:
AUTO - MAN - OOS Specifies the action taken when the upper pre alarm limit value (HI_LIM) is
exceeded.
User input:
0
1
2
3-7
8-15
Factory default:
Description
= the violation of the upper alarm limit is not evaluated.
= no notification if the upper alarm limit is infringed.
= reserved for block alarms.
= the violation of the upper alarm limit is output
as a user notice with the appropriate priority
(3 = low priority, 7 = high priority).
= the violation of the upper alarm limit is output
as a critical alarm with the appropriate priority
(8 = low priority, 15 = high priority).
0
Range and unit of OUT_SCALE
+ INF
= the violation of the upper warning limit is not evaluated.
= no notification if the upper warning limit is infringed.
= reserved for block alarms.
= the violation of the upper warning limit is output
as a user notice with the appropriate priority
(3 = low priority, 7 = high priority).
= the violation of the upper warning limit is output
as a critical alarm with the appropriate priority
(8 = low priority, 15 = high priority).
0
