FOUNDATION Fieldbus temperature transmitter
Endress+Hauser
Are all cable entries installe, tightened and correctly sealed?
Cables looped as "Water traps"?
Are all housing covers installed and firmly tightened?
Electrical connection of FOUNDATION Fieldbus
Are all connection components (T boxes, junction boxes, connectors
etc.) correctly connected with each other?
Has each fieldbus segment been terminated at both ends with a bus
terminator?
Has the max. length of the fieldbus cable been kept within the FF
specifications?
Has the max. length of the spurs been kept within the FF specifications?
Is the fieldbus cable fully shielded (90%) and correctly grounded?
5

Operation

5.1

FOUNDATION Fieldbus technology

The FOUNDATION Fieldbus (FF) is a purely digital, serial communication system that
connects fieldbus devices (sensors, actors), automation and process control systems
with each other. As a local communications network (LAN) for field devices the FF was
primarily designed for the requirements of process technology. The FF thus forms the
basic network throughout the hierarchy of a communication system.

5.1.1 System architecture

The following figure shows two typical examples of a FOUNDATION Fieldbus network
with the associated components.
5 Operation
See page 92
−
Notes
–
–
See page 87
See page 87
See page 88
93
