10 Technical Data
Function blocks
Output signal
Failure signal
Power up current
Filter
Current consumption
Power up delay
Data transmission rate
Signal coding
Galvanic isolation
106
Sensor Measurement range in mV
mV -6 to 22
-10 to 100
-50 to 500
mV DIF. -28 to 28
-110 to 110
OHM 0 to 100
0 to 400
0 to 2000
OHM DIF. -100 to 100
-400 to 400

10.3 Outputs

RESOURCE, TRANSDUCER BLOCK, DISPLAY TRANSDUCER, DIAGNOSTICS
TRANSDUCER, ANALOGUE INPUT, PID CONTROL, ENHANCED PID, ARITHMETIC,
INTEGRATOR, INPUT SELECTOR, SIGNAL CHARACTERIZER, SPLITTER, ANALOGUE
ALARM, SETPOINT RAMP GENERATOR, TIMER, LEAD-LAG, OUTPUT SELECTOR /
DYNAMIC LIMITER, CONSTANT
Physical data tansmission (Physical Layer Type):
• Fieldbus interface to IEC 61158-2
• Integrated polarity protection
Status messages per FOUNDATION-Fieldbus specification
max. 12 mA
Digital filter
12 mA
~10 s
31.25 kBit/s, voltage mode
Manchester II
> 1500 V
DC
FOUNDATION Fieldbus temperature transmitter
Accuracy
±0.02% or ±2 µV
±0.02% or ±10 µV
±0.02% or ±50 µV
±0.1% or ±10 µV
±0.1% or ±50 µV
±0.02% or ±0.01 Ohm
±0.02% or ±0.04 Ohm
±0.02% or ±0.20 Ohm
±0.08% or ±0.04 Ohm
±0.1% or ±0.2 Ohm
