11 Appendix
Index Parameter
14 STATUS_OPTS
3 STRATEGY
2 TAG_DESC
38 TRK_IN_D
37 TRK_SCALE
39 TRK_VAL
43 UPDATE_EVT
156
PID Function Block (PID controller)
Write access with
operating mode
(MODE_BLK)
OOS Selects the available status options for specifying the status processing and
processing of the output parameter OUT.
Options:
Factory default:
ROUT - RCAS - CAS - Parameter for grouping and thus faster evaluation of blocks. Grouping is
AUTO - carried out by entering the same numerical value in the parameter
MAN - OOS STRATEGY for each individual block.
Factory default:
ROUT - RCAS - CAS - Entry of a user-specific text of max. 32 characters for unique identification
AUTO - and assignment of the block.
MAN - OOS
Factory default:
ROUT - RCAS - CAS - Displays the discrete input (value and status) that initiate the external
AUTO - tracking function.
MAN - OOS On activation of tracking the operating mode switches to LO (Local
Compulsory Tracking). In so doing the actuating variable at the output OUT
adopts the value specified at input TRK_VAL.
MAN - OOS Definition of the measurement range (lower and upper limit), the physical unit
and the number of decimal places for the external tracking variable
(TRK_VAL).
Factory default:
ROUT - RCAS - CAS - Displays the analogue input value and input status read in from another
function block for the external tracking function in the unit of parameter
AUTO -
MAN - OOS group TRK_SCALE.
Read only Displays whether static block data has been modified, including date and
time.
FOUNDATION Fieldbus temperature transmitter
Description
IFS if Bad IN
Trigger disturbance status of subsequent
Analogue Output Function Block if the
controlled variable (IN) changes the status to BAD.
IFS if Bad CAS_IN
Trigger disturbance status of subsequent
Analogue Output Function Block if the
external setpoint value (CAS_IN) changes the
status to BAD.
Use Uncertain as Good
The status UNCERTAIN is used as GOOD.
Target In Manual if Bad IN
Switch to operating mode MAN if the
controlled variable switches the status to BAD.
no option active
0
(_____) without text
0...100%
