Remontagem do assento do passageiro
Lubrifique a sede (Y1) do perno (S7) com SHELL GADUS S2 V220
AD 2. Posicione o assento do passageiro (S1) e insira a lingueta (S8)
no alojamento (Y2) presente dentro do porta-luvas. Empurre o as-
sento do passageiro (S1) para baixo para bloquear o perno (S7) na
fechadura do assento.
Certifique-se do engate correto, puxando suavemente o assento
do passageiro (S1) para cima. Retire a chave da fechadura.
28
28
Y2
S8
S1
Passenger seat reassembly
Lubricate the seat (Y1) of pin (S7) with SHELL GADUS S2 V220
AD 2. Position passenger seat (S1) and insert the tab (S8) into the
housing (Y2) present inside the glove compartment. Push the pas-
senger seat (S1) downwards to secure the pin (S7) in the seat lock.
Make sure that the passenger seat (S1) is properly secured by gen-
tly pulling it upwards. Remove key from the lock.
ISTR 1011 / 00
