Setting measuring and control parameters

8.5.2 Version: Sensors and parameters

8.6 Settings menu

8.6.1 Version: Standard

112
Flow meter settings
Parameter with assigned flow sensor
pH value
Fig. 115: Flow meter settings
In this example, the pH parameter is influenced by a flow sensor.
The flow control threshold setting is specific to the pH parameter.
The screen shows the configured parameters and flow parameters.
You can configure the active flow rate parameters by pressing the
display field.
'Tank liquid level 4 ... 20 mA'
'Tank liquid level 4 ... 20mA' menu enables the lower
The
threshold of the tank volume to be set, which is subject to
metering.
This menu is only accessible if you have set up a volume sensor in
the installation. Otherwise, the menu remains grey.
The liquid level is only one parameter. The controller and the set‐
ting of the lower threshold value are applied at parameter level and
are identical for all parameters controlled by this liquid level.
Storage tank liquid level settings
Fig. 116: Liquid level, version: Standard
The screen shows the configured liquid level parameters. You can
configure the lower threshold value of the storage tank by pressing
an active parameter.
Free chlorine
Salt content
Storage tank liquid level settings
pH value
Temperature
Band
Flow rate settings
Flow rate
Free chlorine
Flow rate
A3162
A3163
