Functional description

1 Functional description
ECU
Fig. 1: Functional elements of the complete system
1. Swimming pool
2. Metering pump for chlorine
3. Metering pump for acid (pH)
4. Heat exchanger
5. Secondary flow filter for the bypass fitting
6
The swimming pool controller was designed to measure and con‐
trol temperature, pH, chlorine or bromine values using sensors and
the control in conjunction with the corresponding adjustable com‐
ponents of the entire system.
The swimming pool controller will henceforth be referred to as the
'controller' throughout these operating instructions.
1.
5.
6.
9.
8.
6.
7.
8.
9.
ECU Electronic Control Unit
2.
3.
4.
7.
In-line probe housing
Primary flow filter for the swimming pool
Circulating pump
Compensation tank
[Electronic Control Unit]
A1532
