CHOKE
10x
ON
34 | GB
Pushed in - choke deactivated
Pulled out - choke activated
Primer button for cold start
Adjusting screws for carburettor:
L Low engine speed
H High engine speed
T Idle speed
Adjusting the chain brake:
White arrow: Chain brake inactive.
Black arrow: Chain brake active.
Installation direction of the saw chain.
Guaranteed sound power level of the device.
Attention! Hot surface.
On/off switch - "ON"
On/off switch - "STOP"
Weight
Mixing ratio
Avoid contact with the rail tip.
Fire prohibited.
The product complies with the applicable European directives.
The product complies with the applicable Serbian directives.
