10.3 Wykresy plamek świetlnych
8027716/2022-04-12 | SICK
Z zastrzeżeniem zmiany bez powiadomienia
WTM12L-xxxxx8xx

MultiMode

Dimensions in mm (inch)
2
1/3/4/5:
(0.08)
1
(0.04)
0
–1
(–0.04)
–2
(–0.08) 0
Rysunek 24: WTM12L-xxxxx8xx, MultiMode 1/3/4/5
MultiMode 2:
Dimensions in mm (inch)
2
(0.08)
1
(0.04)
0
–1
(–0.04)
–2
0
(–0.08)
Rysunek 25: WTM12L-xxxxx8xx, MultiMode 2
MultiMode 6 i M:
Dimensions in mm (inch)
2
(0.08)
1
(0.04)
0
–1
(–0.04)
–2
0
(–0.08)
Rysunek 26: WTM12L-xxxxx8xx, MultiMode 6 i M
INSTRUKCJA EKSPLOATACJI
100 200 300 400 500
(3.94) (7.87) (11.81) (15.75) (19.69)
Distance in mm (inch)
Recommended sensing range for
the best performance
50 100 150
(1.97) (3.94) (5.91)
Distance in mm (inch)
Recommended sensing range for
the best performance
200 400 600 800
(7,87) (15,75) (23.62) (31,50)
Distance in mm (inch)
Recommended sensing range for
the best performance
I N S T R U K C J A E K S P L O A T A C J I | WTM12L MultiMode
15 160 420
(0.59) (6.30) (16.54)
20 120 150
(0.79) (4.72) (5.91)
25 200 650
(0.98) (7.87) (25.59)
241
