10.3 Diagrammi punto luminoso
8027716/2022-04-12 | SICK
Contenuti soggetti a modifiche senza preavviso
WTM12L-xxxxx8xx

MultiMode

Dimensions in mm (inch)
2
1/3/4/5:
(0.08)
1
(0.04)
0
–1
(–0.04)
–2
(–0.08) 0
Figura 24: WTM12L-xxxxx8xx, MultiMode 1/3/4/5
MultiMode 2:
Dimensions in mm (inch)
2
(0.08)
1
(0.04)
0
–1
(–0.04)
–2
0
(–0.08)
Figura 25: WTM12L-xxxxx8xx, MultiMode 2
MultiMode 6 e M:
Dimensions in mm (inch)
2
(0.08)
1
(0.04)
0
–1
(–0.04)
–2
0
(–0.08)
Figura 26: WTM12L-xxxxx8xx, MultiMode 6 e M
100 200 300 400 500
(3.94) (7.87) (11.81) (15.75) (19.69)
Distance in mm (inch)
Recommended sensing range for
the best performance
50 100 150
(1.97) (3.94) (5.91)
Distance in mm (inch)
Recommended sensing range for
the best performance
200 400 600 800
(7,87) (15,75) (23.62) (31,50)
Distance in mm (inch)
Recommended sensing range for
the best performance
I S T R U Z I O N I P E R L ' U S O | WTM12L MultiMode
ISTRUZIONI PER L'USO
15 160 420
(0.59) (6.30) (16.54)
20 120 150
(0.79) (4.72) (5.91)
25 200 650
(0.98) (7.87) (25.59)
173
