РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
10.3 Схемы световых пятен
ru
312 Р У К О В О Д С Т В О П О Э К С П Л У А Т А Ц И И | WTM12L MultiMode
WTM12L-xxxxx8xx

MultiMode

Dimensions in mm (inch)
2
1/3/4/5:
(0.08)
1
(0.04)
0
–1
(–0.04)
–2
(–0.08) 0
Рисунок 24: WTM12L-xxxxx8xx, MultiMode 1/3/4/5
MultiMode 2:
Dimensions in mm (inch)
2
(0.08)
1
(0.04)
0
–1
(–0.04)
–2
0
(–0.08)
Рисунок 25: WTM12L-xxxxx8xx, MultiMode 2
MultiMode 6 и M:
Dimensions in mm (inch)
2
(0.08)
1
(0.04)
0
–1
(–0.04)
–2
0
(–0.08)
Рисунок 26: WTM12L-xxxxx8xx, MultiMode 6 и M
100 200 300 400 500
(3.94) (7.87) (11.81) (15.75) (19.69)
Distance in mm (inch)
Recommended sensing range for
the best performance
50 100 150
(1.97) (3.94) (5.91)
Distance in mm (inch)
Recommended sensing range for
the best performance
200 400 600 800
(7,87) (15,75) (23.62) (31,50)
Distance in mm (inch)
Recommended sensing range for
the best performance
15 160 420
(0.59) (6.30) (16.54)
20 120 150
(0.79) (4.72) (5.91)
25 200 650
(0.98) (7.87) (25.59)
