Installation
Check the sensor circuit
using the installation
checker, VIB 8.745
How to connect the vibration
sensors to the MUX
• Use the VIB 8.745 installation checker to test the circuit. The condi-
tion is indicated by one of the three LEDs on the housing: 'Ground
loop', 'OK', 'Short circuit'.
• If the circuit is 'OK', connect the cable to the MUX terminal.
• Tighten down the fitting.
Machine
potential
String line
connection terminal
S2
S4
S6
S8
S1
S3
S5
S7
S9
Fittings
Sensor connection
terminal (S1 to S9)
S2
S1
S2
S4
S6
S8
S1
S3
S5
S7
S9
